Customization Panel Dimensions BIPV 10w Small Mono Solar Charger for Mobile Phone

Product Categories

Shenzhen JTN Solar Energy Co., Ltd.

Contact Now

Customization Panel Dimensions BIPV 10w Small Mono Solar Charger for Mobile Phone

Brand Name : OEM

Model Number : JTN-M300W-B, JTN-M300W-B

Place of Origin : Guangdong, China

Packaging Details : packing in carton box

Supply Ability : 5000000 Piece/Pieces per Month

MOQ : 100000 watts

Price : $0.22/watts 100000-199999 watts

Cell size : 125mmx125mm, 125mm*125mm/Other

Type : Half Cell, BIPV, Flexible

Panel Dimensions : customization

Panel Efficiency : 19.8%-22.5%

Warranty : 3years

Protable Name : Home Use Solar Panel

Waterproof : IP65

Logo print : customization

Workmanship : 12 years

Solar cell : Monocrystalline

Surface material : PET/ETFE/glass

Output mode : MC4/DC/Anderson

Connector : Compatible Connector or customized

Port : SHENZHEN

Contact Now

High quality 22% efficiency small mono 10w mobile phone mini solar panel charger

Products Description

Customization Panel Dimensions BIPV 10w Small Mono Solar Charger for Mobile Phone

Model	JTN-(XXX)W-B (XXX)=Pmax/W						JTN-(XXX)W-B (XXX)=Pmax/W
Maximum Power(Pmax/W)	100	150	160	200	250	300
Open-circuit Voltage (Voc/V)	21.6	32.14	21.6	43.4	33.33	39.3
Short-circuit Current (Isc/A)	6.1	6.1	9.7	6.1	9.9	10.08
Maximum Power Voltage(Vmp/V)	18	26.8	18	36.2	27.8	32.75
Maximum Power Current (Imp/A)	5.6	5.6	8.9	5.5	9	9.16
Solar Panel Efficiency(%)	19.8-22.5%						19.8-22.5%
Power Tolerance(W)	0~+5W						0~+5W
Standard Test Environment	Irradiance 1000w/m2, Ambient temperature 25℃, Spectrum AM 1.5

Model	JTN-M(XXX)W-B (XXX)=Pmax/W
Maximum Power(Pmax/W)	370	400	450	455	480	customize
65.29Open-circuit Voltage (Voc/V)	28.8	21.6	24	26.4	33.6	/
Short-circuit Current (Isc/A)	17	24.4	24.75	22.75	18.9	/
Maximum Power Voltage(Vmp/V)	24	18	20	22	28	/
Maximum Power Current (Imp/A)	15.4	22.2	22.5	20.7	17.1	/
Solar Panel Efficiency(%)	19.8-22.5%
Power Tolerance(W)	0~+5W
Standard Test Environment	Irradiance 1000w/m2, Ambient temperature 25℃, Spectrum AM 1.5

Model	JTN-M(XXX)W-B (XXX)=Pmax/W
Maximum Power(Pmax/W)	500	535	540	545	550	customize
Open-circuit Voltage (Voc/V)	43.2	28.8	26.4	88.02	88	/
Short-circuit Current (Isc/A)	15.28	24.5	27	8.17	8.25	/
Maximum Power Voltage(Vmp/V)	36	24	22	7.43	7.5	/
Maximum Power Current (Imp/A)	13.9	22.3	24.6	7.43	7.5	/
Solar Panel Efficiency(%)	19.8-22.5%
Power Tolerance(W)	0~+5W
Standard Test Environment	Irradiance 1000w/m2, Ambient temperature 25℃, Spectrum AM 1.5

Q :Are you manufacturer or trading company?
A : We are manufacturer with more than 10 years experience and can control the production of goods quality and delivery time.

Q : What kind of certificates your products have?
A : CE,FCC,RoHS,PSE,MSDS

Q : What's your products MOQ?
A : MOQ is 50 pcs.

Q : How about your delivery time?
A : Generally,our stock products would be shipped in 1-3 days after payment received. finally depends on order quantities.

Q : What's your warranty?
A : All our products will be 100% test before shipment. Warranty 2 years.

Q : What is the payment method?
A: We accept payment by T/T, Credit card, Alibaba platform, Western Union and etc.
